Double color straw extruder from China manufacturer - Qingdao Shunlida Plastic Machinery Co., Ltd

Payment Terms:	T/T,L/C
Place of Origin:	Shandong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: SJ-65/30

Production Capacity: 60 Set/Sets per Year

Delivery Date: 40working days after receiv...

Use: Others

Brand Name: shunlida

output: 25-35kg/h

Means of Transport: Ocean

Packing: wooden carton or standard p...

Plastic Type: PP/PE

Shaft Design: Single

Power: 78kw

By replacing the head, the line can produce a variety of products,It is muti function.

Conveyor motorField of application:
1.Food industry: drink straw, candy bars, coffee bar, oral liquid straw
2.Other industries: a signature pen core head tube, rod, balloons, small flag, the cotton swab stick, medical tube

Techinical specification:

model		ML11	ML12	ML13
L/D		φ50mm/28:1
L/D		0	1×φ25mm/20:1	2×φ25mm/20:1
output		25~35Kg/h
power	The main screw motor	11kW 380v 50Hz ()
	The auxiliary screw motor	0	0.75kW×1	0.75kW×2
	Traction motor	0.75kW×1
	The cutting motor	0.75kW×1
	Conveyor motor	0.18kW×1
Temperature control settings		5sections	8sections	11 sections
Cooling and sizing flume length		2400mm/3400mm/4400mm
Specifications		diameter:φ2~14mm Wall thickness:0.05~1.00mm
Special specifications can be customized restructuring
