Product Detail

Model No.: SJ90/33

Production Capacity: 5 sets every month

Delivery Date: within 60 working days afte...

Use: Others

Brand Name: shunlida

Model Number: SJ90/33

Processing type: Extruding machine

Certification: CE

screw structure: single screw

capacity: 200-300kg/h

Means of Transport: Ocean

Packing: Export packing, covered wit...

Plastic Type: PP/PE

Shaft Design: Single

Power: 200Kw

Product type: plastic sheet

Line speed(max): 10m/min

Main motor power: 200Kw

Forming rollers: 300-500mm diameter

color: as the customer request

Pe Plastic sheet Machinery
The line has the advantages of well-planned layout ,compact in structure
.fine in performance .

LDPE HDPE Plastic sheet extrusion molding machinery

The lines have the advantages of well-planned layout, compact in structure, fine in performance such as homogenous plasticization, high output and long service life. The screws and barrels are made of special alloy and the structure is optimized. Exchanging screen rapidly about 1.5 seconds every times, the screen changer unit don't need the downtime. The cutting unit can guarantee the precise measurements through the adjustment of length and width, the error of product's diagonal<3mm, the using range of products is wide. The line can adopt one, two, three extruders together to do one layer, multi-layer plastic sheet. The electric control system utilize imported frequency converter, it's safe and reliable. The lines are suit for PP, PE, PC, PS, ABS, PVC, PMMA, PET, HIPS etc.

Multi-Layer Co-Extrusion
The line can adopt one, two, three extruders together to do one layer, multi-layer plastic sheet.

Melt Pump System
Stable extrusion to produce higher quality product.

Intelligentized Control System
The function of fault alarm can be controlled by PLC with simple operation.

Cutting Manchine System
Flexible length adjustment according to requirements.

MAIN TECHNICAL PARAMETERS:

* Model	SD-1000	SD-1400
Diameter Of Screw	Ø90mm	Ø120mm
Speed Of Screw	0~110r.p.m	0~100r.p.m
Height Of Center	1000mm	1150mm
Output	180kg/h	300kg/h
Roller Dimensions	Ø400×1000mm	Ø400×1400mm
linear Speed	0.2~6m/min	0.2~6m/min
Operation Power (about)	138Kw	190Kw
width Of Products	850mm	1250mm
Weight (About)	12T	16T
Overall Dimensions	10000×3200×2000mm	30000×3600×2500mm
* Other Models for different production not full completely listed here.

Standard Equipment	Optional Device
Granulate Loader Extruder Automatic Filter Changer T-Die Three Rollers Transmit Cooling Device Cutting Machine System	Co-Extrusion Multiple component dosing unit Melt pump system Corona pre-treating system Distributor

Specification and dimensions are subject to change without prior notice.
