plastic PVC pipe extrusion machine from China manufacturer - Qingdao Shunlida Plastic Machinery Co., Ltd

Payment Terms:	T/T,L/C
Place of Origin:	Shandong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: SJZ65/132

Production Capacity: 60 sets every year

Delivery Date: within 45 working days from...

Use: Others

Brand Name: shunlida

pipe diameter range: 16mm-250mm

screw material: 38CrMoAIA

application: drainage, sewage

screw heating type: electric heating

certification: CE

Means of Transport: Ocean,Air

Packing: packed in wooden case

Plastic Type: PVC

Shaft Design: Double

Power: 130Kw---350Kw

screw type: double screw

Dimension(L*W*H):: 20m*2.5m*2.5m

Type: pipe extrusion machine

pipe extrusion line: pipe extrusion machinery

Category: plastic extruder

1.The machine can be changed to produce PPR/PP/PE pipe.
2.Their wall thickness is different according to different pressure standard.

Description of PVC Water Pipe Extrusion Machine:

QingdaoShunlida Plastic Machinery Co., Ltd designs and develops PVC pipe extrusion Machine especially for PVC water supply and drain pipe.PVC water pipe extrusion machine is specializing in manufacturing PVC,CPVC and UPVC pipes of different diameter and thickness.They are applied to agricultural and construction water supply and drainage, overhead or underground wire and cable.Due to the special characteristics of the CPVC plastic pipes,
Application of pipes:
pvc pipe mainly use in agricultural and construction water supply-drainage.cpvc pipe due to its special character, widely use in base oil transportation,temperature and corrosion resistance pipe of chemical,hot water supply-drainage pipe and protection pipe of high voltage electricity and electrical cables.

Features of this PVC Pipe Extrusion Machine:
1. Advanced screw design ensures PVC high speed extrusion
2. Reliable temperature control system ensures the high quality
3. Use electric parts (Motor/Breaker/Inverter/relay and so on ) which is Siemens /Schneider/Omron. It can improve machine operation stable.
4. Inner heat exchange unit effects more convenient extrusion.
5. Precise calibration unit with fast cooling design ensure high production speed
6. Center height is adjustable
7. Adopt PLC control for easy operation.
8. This PVC water pipe extrusion machine includes automatic forced feeding system/extruder/die head and mold/vacuum cooling tank/spray cooling tank/haul off/ cutting machine/tilter.Vacuum pump and tractor adopts high-quality products. Tractors can be divided into up and down pedrail, three-claw, four-claw, six-claw, etc. in terms of thickness and diameter of the pipe. The cutter has two modes of cutting such as blade and planet type. Additionally, metering device is equipped. The property of the production machine is reliable and the output is high.
Main technical parameters

Model	SJZ51/105	SJZ65/132	SJZ80/156	SJZ92/188
Motor power(kw)	22	37	55	110
Diameter of screw(mm)	55/110	62/132	80/156	92/188
Screw quantities	2	2	2	2
Screw torque (N.m)	7000	10000	14000	32000
Maximum output (kg/h)	100	200	350	500

what is your advantage in comparison with other companies?

1.Firstly,we could reduce the labor cost and routine management cost.So our machine is with lower cost.

2. Secondly,we have an intelligent team including engineers and salespersons with the same experience like the ones working in big factories.So,do not worry about our capability.

3. Thirdly,we could guarantee the electrical and mechanical components for one year since the machine could run smoothly in your plant.
