PVC pellets making machine from China manufacturer - Qingdao Shunlida Plastic Machinery Co., Ltd

Payment Terms:	T/T,L/C,WU
Place of Origin:	Shandong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: SJZ51/105

Production Capacity: 60 set/sets every year

Delivery Date: 45 days from the deposit

Use: Others

Brand Name: shunlida

Material: PVC powder

Product type: PVC granules

screw material: 38CrMoAiA

machine total length: 14m

certification: CE passed

Means of Transport: Ocean

Packing: Wood pallet covered by plas...

Plastic Type: PVC

Shaft Design: Double

Power: 120Kw

Processing machine: extruding machine

screw type: double - screw

barrel material: 38CrMoAiA

net-changer method: hydraulic screen changer

capacity: 350kg/h

waste PVC pellets making machine
1.high output:400KG/H
2.conical double screw:55mm
3.main motor power:55KW
4.certificate:CE and ISO9001:200

1.high output:400KG/H
2.conical double screw:55mm
3.main motor power:55KW
4.certificate:CE and ISO9001:2000

The Features and Application:

It is featured as advanced equipment, strong commonality and high producing capacity.

With different designs of screw , this machine can be applied to granulate the recycled material of rigid PVC , soft PVC and waste PVC . It can be stopless in the course of production . It uses pneumatic conversion and strong-wind blowing . At the same time can adjust stainless steel storage container and can run at high speed for a long time while extrude stably.

Main Technical Parameters:

Model	SJZ45/90	SJZ51/105	SJZ55/110	SJZ55/115	SJZ65/132	SJZ80/156	SJZ92/188
Power of drive motor(Kw)	15	18.5	22	22	37	55	110
Screw diameter(mm)	45/90	51/105	55/110	55/115	65/132	80/156	92/88
No. of screw	2	2	2	2	2	2	2
Torsional moment of screw	3148	6000	7000	7000	10000	10000	32000
Capacity (kg/h)	60	100	120	180	250	400	750
Dimension(mm)	336012902127	336012902127	362010502157	362010502157	371515202450	475015502460	672515502814
