Qingdao Shunlida Plastic Machinery Co., Ltd
|
| Payment Terms: | T/T,L/C |
| Place of Origin: | Shandong, China (Mainland) |
|
|
| Add to My Favorites | |
| HiSupplier Escrow |
Max. Product volume | 4 liters |
Dry cycle | 800X2pc/h |
Screw diameter | 65mm |
Screw L/D ratio | 24 L/D |
Screw drive power | 18.5 KW |
Screw heating capacity | 5.7 KW |
No.of heating zone | 3 zones |
Output of HDPE | 80 KG/H |
Oil pump drive power | 7.5 KW |
Clamping force | 45 KN |
Max.size of mold | 148-508mm |
Mold stroke | 320X360mm |
Max.die diameter | 140mm |
Blow pressure | 0.6mpa |
Air volume | 0.7 M³/MIN |
Cooling water pressure | 0.3mpa |
Water consumption | 65 L/MIN |
electronic parts | |
Name | Trader |
Micro computer control system | Japanese MITSUBISHI |
Temperature Controller | HuiBang PID |
Auxiliary Relay | OMRON |
contactor | Schneider from France |
Electric motor | Three phase 220V or 380V |
Power Source | TAIWAN MEANWELL |
Transducer | TAIDA FROM CHINA |
hydraulic parts | |
Name | Trader |
Oil pump | Japan YUKEN |
Valve | Japan YUKEN |
Oil pump and connection | Japan YUKEN |
Sealed part | HALLITE |
air control system | |
Name | Trader |
Cylinder | AIRTAC |
Air Valve |
