PE PP film recycling and granulating Line

Payment Terms:	T/T,L/C,WU
Place of Origin:	Shandong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: SJ-150/120

Production Capacity: 60 set/sets every year

Delivery Date: 45 days from the deposit

Use: Others

Brand Name: shunlida

Material: waste PE PP

Product type: PE granules

screw material: 38CrMoAiA

machine total length: 14m

certification: CE passed

Means of Transport: Ocean

Packing: Wood pallet covered by plas...

Plastic Type: PP/PE

Shaft Design: Single

Power: 120Kw

Processing machine: extruding machine

screw type: single - screw

barrel material: 38CrMoAiA

net-changer method: hydraulic screen changer

capacity: 350kg/h

Double-ranks Recycling & Granulating Line
1. exhaust type recycle UNIT
2.can be customized
3.meet CE standard
4.high capacity

Double-Ranks Granulating line is mainly used to recycle and reprocess waste and new plastic PE, PP.

1.Double-Ranks Granulating line

1) Double-ranks Recycling & Granulating System is mainly used to recycle and reprocess waste and new plastic PE, PP.
2) We use force feeding, as the screw can exclude gas and steam. After plasticization and extrusion, the particles can have high density, nice surface, high output, stable extrusion. Customers can certainly adopt which feeder they like.
3) Production capacity: 100-500kg/h.
4) These machinery are for different customers to choose. And we could also design special granulator line according to the customers' request.

2. Design and Detailed technical parameters for 300kg/h is as follows: If you need other capacity, feel free to contact us.

Number	Description	Technical parameters	Quantity
1	Force feeder	1) Motor Power: 2.2KW, and use inverter to adjust the speed. 2) Feeding Method: Screw Force Feeding. 3) Process Material: Stainless Steel 4) Feeding Capacity: 500kg/h	One set
2	SJ150/28 Single Screw Extruder	1) Screw Diameter: Φ150mm 2) L/D: 28 : 1 3) Motor Power: 75KW, and use inverter to adjust the speed. 4) Screw, Material barrel are made of 38CrMoAlA, through nitrogen treatment, with water-drainage and air-exhaust function. 5) Use extruder specific hard tooth surface gear box: ZLYJ-250 6) Cylinder Heating Power: Total power 48KW, 6 Zones, 8KW/Zone; heater is made of ceramic, with stainless steel shield outside. 7) Cylinder cooling: 6 Zones, 0.24KW/Zone. 8) Non-stop mesh-change oil pump power: 3KW 9) Mesh-change type: Plate valve 10) Screw rotary speed: 10-110rpm 11) Output: 300kg/h	One set
3	SJ120/10 Single Screw Extruder	1) Screw Diameter: Φ120mm 2) L/D: 10 : 1 3) Motor Power: 37KW, and use inverter to adjust the speed. 4) Screw, Material barrel are made of 38CrMoAlA, through nitrogen treatment. 5) Use extruder specific hard tooth surface gear box: ZLYJ-173 6) Cylinder heating power: total power is 18KW, 3 Zones, 6KW/Zone, and heater material is made of ceramic, with stainless steel shield outside. 7) Cylinder cooling: 3 Zones, 0.24KW/Zone. 8) Mesh-change equipment hydraulic station and SJ150/28 extruder use the same one. 9) Screw rotary speed: 10-120rpm. 10) Output: 300kg/h.	One set
